Technical specifications
Published reference data for the vehicle discussed in this guide. Confirm the selected build in the supplier’s specification.
| Parameter | Published value |
|---|---|
| Vehicle model | HYS5040XDYJ6 |
| Chassis | JMC JX1041TG26 |
| Wheelbase | 3,360 mm |
| Reference dimensions | 5,995 × 2,100 × 3,000 mm |
| Gross vehicle mass | 4,495 kg |
| Curb mass | 4,365 kg |
| Published output voltage | 380 / 220 V |
| Published frequency | 50 Hz |
Applications and route planning
Utility teams, maintenance contractors and event operators may need temporary power at locations without a reliable fixed connection. This JMC reference carries generation and distribution equipment in an enclosed body. Start with a load schedule and the operating site, because generator selection depends on the equipment being powered and the expected duty cycle.
Understanding the technical specification
The source table labels an 85 kW / 115 hp figure as generator power while repeating an engine-style rating. That ambiguous output is excluded. Request the generator make, continuous kW and kVA ratings, power factor and load-step performance. The listed 380/220 V and 50 Hz figures still need to match the destination equipment and connection scheme.
Configuration and quotation checklist
List running loads, starting loads, cable distances and the desired operating duration. Confirm the distribution panel, connectors, earthing arrangement, ventilation and noise specification. Include crew, fuel, cables and accessories in the vehicle weight review; the published curb and gross masses leave little unallocated capacity.
Maintenance, inspection and handover
Arrange load-bank testing and a record of the installed generator and protective equipment. Ask for filter, belt and service-part references. Qualified personnel should review the electrical connections and operating procedures for the intended site.
Ordering for your destination
Send your destination country, preferred chassis support network and required delivery location with the vehicle brief. Ask for a dated quotation that separates the chassis, specialist body, equipment, inspection, spare parts and freight. Confirm the deposit, production milestones and shipment documents in the contract. Transit time and import costs depend on the agreed route and destination; they are not fixed by this reference guide.
Reference scope
The figures describe the published reference, not every configuration. Final chassis, body equipment, permitted payload, destination requirements, delivery schedule and price are confirmed in a written quotation.
