Technical specifications
Published reference data for the vehicle discussed in this guide. Confirm the selected build in the supplier’s specification.
| Parameter | Published value |
|---|---|
| Vehicle model | YZR5200GXFSG80/Q6 |
| Chassis | Isuzu QL5220GXFFMFRY |
| Drive layout | 4×2 |
| Wheelbase | 4,500 mm |
| Dimensions | 8,250 × 2,540 × 3,600 mm |
| Gross vehicle mass | 19,800 kg |
| Water capacity | 8,400 L |
| Fire pump duty | 60 L/s at 1.0 MPa |
| Monitor duty | 50 L/s at 0.8 MPa |
| Engine | 6HK1-TCG60, 221 kW |
Applications and route planning
This water-tank appliance provides a reference for fire services and industrial response teams comparing a medium-to-large water-carrying vehicle. The manufacturer lists 8,400 L of water and an Isuzu 4×2 chassis. Selection starts with the response area, water-replenishment plan, equipment inventory and the access available at the intended operating sites.
Understanding the technical specification
The pump and monitor figures refer to different flow-pressure points and should be evaluated separately. Stored water volume does not establish sustained operational duration without a defined deployment. The chassis gross rating also differs from the completed appliance mass; use the completed vehicle’s approved weight schedule for procurement and loading discussions.
Configuration and quotation checklist
Provide the crew requirement, hose and coupling standards, equipment list and expected water sources. Request pump-test records, the body layout and an itemised supplied-equipment schedule. Check overall height and width against station doors, routes and site entrances before deciding on this vehicle class.
Maintenance, inspection and handover
Plan operator familiarisation, pump servicing and spares for the supplied valves and seals. The acceptance scope should identify performance tests and documentation required by the purchasing fire service. Reference photographs do not establish certification for another destination.
Ordering for your destination
Send your destination country, preferred chassis support network and required delivery location with the vehicle brief. Ask for a dated quotation that separates the chassis, specialist body, equipment, inspection, spare parts and freight. Confirm the deposit, production milestones and shipment documents in the contract. Transit time and import costs depend on the agreed route and destination; they are not fixed by this reference guide.
Reference scope
The figures describe the published reference, not every configuration. Final chassis, body equipment, permitted payload, destination requirements, delivery schedule and price are confirmed in a written quotation.
